Introduction
DTD-02G Glass Liquid Thermometer Reading Device is a reading device for detecting glass liquid thermometer. It uses CCD technology to display the thermometer score on the monitor, which can enlarge the score by more than 20 times and can also be used for other images magnified observation.
Function
? Adopt high-power optical lens and magnifying expansion port, the magnification is large, the image is clear, and the reading is accurate; it greatly reduces the eye fatigue caused by the long observation time of the inspector and avoids the occurrence of gross errors.
? The observation field is large, which can be observed by one or more people at the same time.
? The magnification can reach more than 20 times.
? The image acquisition adjustment is sensitive and practical.
? It can replace reading telescope which has been used for more than 30 years. The whole set of equipment includes observation and display parts, and the equipment is sensitive to adjustment and easy to move.
? 15-inch industrial-grade high-performance LCD screen, reasonable size, compact structure, easy to place.
? The display adopts high-strength steel shell, which can provide good protection; professional-grade chips and processing technology to ensure high image quality; high reliability and stability, especially suitable for harsh industrial environments.
? Use industrial camera: DSP-digital signal processing technology, make the image clearer and more delicate, the outline is clearer, the signal-to-noise ratio and the contrast are stronger.
